Adjustable metal support for elevated flooring, with self-levelling tilting head that can correct slopes up to 5%.
The support consists of a 100mm x 100mm square base which is 1.8mm thick, and a screw of threaded bar at the end of which is fixed a concave element that acts as the support seat of the tilting head. The support is completed by a self-levelling tilting head with 4mm tabs and an anti-tilting locking ring.
SMA is suitable for use in Paving applications.
Height adjustment is done manually with a 4mm Allen key; the support can reach heights ranging from 27mm to 458mm.
Areco supply A1 fire‑rated pedestals engineered to deliver non‑combustible, adjustable support for decking and paving systems which are ideal for projects requiring enhanced fire safety and robust performance.
Adjustable metal support for elevated flooring, with self-levelling tilting head that can correct slopes up to 5%.
The support consists of a 100mm x 100mm square base which is 1.8mm thick, and a screw of threaded bar at the end of which is fixed a concave element that acts as the support seat of the tilting head. The support is completed by a self-levelling tilting head with 4mm tabs and an anti-tilting locking ring.
SMAT is used in conjunction with the Eterno Ivica Joist System and is suitable for use in Decking and Paving applications.
Height adjustment is done manually with a 4mm Allen key; the support can reach heights ranging from 27mm to 458mm.
