A full range of shapes and sizes are available including domes, squares, rectangles, circles and pyramids. Within the range are options for the rooflights to be produced with fixed tops or openings for ventilation.
The ventilation can be provided by various methods including, worm-gear opening, open and close ventilation strips and access hatches.
Areco Rooflights can also be supplied with various different layers of glazing to help achieve U values and clear and opal finishes to provide UV protection. Areco Rooflights are also available with automatic rain sensors on electric opening versions.
For further technical information, visit www.coxdome.co.uk.
Manual opens to approx. 300mm
Electric opens to approx. 400mm
Suitable with all upstands
Automatic Smoke / Heat ventilation certified to en12101-2
Available in a range of sizes with glazed or solid top.
Opens to 78° on gas assisted struts
160mm Vertical upstand
Our team is available to assist with specifying the best daylight solution to meet your project needs – from initial design through to aftersales support. For sales or technical support on any of the COXDOME product range please contact our Sales Team on 01922 743553.
Finished Roof Opening Size = Rooflight Size
SF15= 150mm splayed insulated upstand
R016=160mm vertical insulated upstand
Single, Double, Triple, Quadruple Clear, Diffused
PC = Polycarbonate
Available in square, rectangle, circular or pyramid
Fixed, Manual Hinge or Electric Hinge
Hit and Miss Ventilation – only available in splayed upstands
Areco supply a wide range of high‑performance rooflights for flat roofing systems, offering various sizes, shapes and glazing options to maximise natural daylight and enhance ventilation or thermal performance for your project.
| ROOFLIGHT SIZE | GLAZING | OPENING OPTIONS | ||||
| DOME | PYRAMID / TRAPEZOID | MANUAL | ELECTRIC | ROOFTOP ENTRANCE | ROOFTOP ACCESS | |
| 600 x 600 |  |
|
|
|
|
|
| 600 x 900 | |
|
|
|
||
| 600 x 1200 | |
|
|
|||
| 700 x 700 | |
|
|
|
|
|
| 700 x 1200 | |
|
|
|
||
| 750 x 750 | |
|
|
|||
| 750 x 900 | |
|
|
|
||
| 800 x 800 | |
|
|
|
|
|
| 800 x 1100 | |
|
|
|
||
| 800 x 1400 | |
|
|
|||
| 900 x 900 | |
|
|
|
|
|
| 900 x 1200 | |
|
|
|
|
|
| 900 x 1500 | |
|
|
|||
| 900 x 1800 | |
|
|
|||
| 1000 x 1000 | |
|
|
|
|
|
| 1000 x 1500 | |
|
|
|
||
| 1000 x 1800 | |
|
|
|||
| 1000 x 2000 | |
|
|
|
||
| 1000 x 2400 | |
|
|
|||
| 1000 x 2500 | |
|
|
|||
| 1000 x 3000 | |
|
|
|||
| 1100 x 1100 | |
|
|
|
|
|
| 1100 x 1400 | |
|
|
|||
| 1200 x 1200 | |
|
|
|
|
|
| 1200 x 1500 | |
|
|
|
||
| 1200 x 1800 | |
|
|
|||
| 1200 x 2100 | |
|
|
|||
| 1200 x 2200 | |
|
|
|||
| 1200 x 2400 | |
|
|
|
||
| 1200 x 2500 | |
|
|
|||
| 1200 x 2700 | |
|
|
|||
| 1200 x 3000 | |
|
|
|||
| 1300 x 1300 | |
|
|
|||
| 1400 x 1400 | |
|
|
|
||
| 1500 x 1500 | |
|
|
|
||
| 1500 x 1800 | |
|
|
|||
| 1500 x 2500 | |
|
|
|||
| 1500 x 2700 | |
|
|
|||
| 1500 x 3000 | |
|
|
|||
| 1600 x 1600 | |
|
|
|
||
| 1700 x 1700 | |
|
|
|
||
| 1800 x 1800 | |
|
|
|
||
| 1800 x 2400 | |
|
|
|||
| 1800 x 2500 | |
|
|
|||
| 1800 x 2700 | |
|
|
|||
| 1800 x 3000 | |
|
|
|||
| 2000 x 2000 | |
|
|
|
||
| 2200 x 2200 | |
|
|
|
||
